악기 정보

Music 2012.08.18 17:29


7-8-12채널 페달파워

http://www.mule.co.kr/instrument/2/bbscontent.aspx?sort=15&idx=2146880

파워 서플라이 문의/주문은



//==================================================================================


베이스 앰프

Laney
RB W \ kg
1 15 ₩153,000 9.5
2 30 ₩234,000 11.7  모노잭 DI, 외부 캐비닛(4옴 이상)
3 65 ₩360,000 18.5  캐비닛 지원(8옴 이상), FX send return
4 160 ₩450,000 25.2  이큐, 캐논잭 DI
5 120 ₩620,000 18.4  모니터형, Presence 노브
6 165 ₩760,000 26.5  모니터형
7 300 ₩800,000 25.0  모니터형
8 300 ₩810,000 30.0



//==================================================================================

길거리 공연용 앰프

* roland cube street - 5w, 5.2kg - 40만
http://www.roland.com/products/en/CUBE_Street/specs.html
Rated Power Output 2.5 W + 2.5 W
Nominal Input Level (1 kHz) MIC/LINE Channel: -50 / -10 dBu
GUITAR/INSTRUMENT Channel: -10 dBu
STEREO AUX IN: -10 dBu
Speakers 16 cm (6.5 inches) x 2
Controls POWER Switch
(MIC/LINE Channel)
SELECT Switch (MIC/LINE), VOLUME Knob, EQUALIZER Knobs (BASS, TREBLE), DELAY/REVERB Knob
(GUITAR/INSTRUMENT Channel)
TUNER Switch, TYPE Switch, GAIN Knob, VOLUME Knob, EQUALIZER Knobs (BASS, MIDDLE, TREBLE), EFX Knob, DELAY/REVERB Knob
Indicators TUNER
POWER
Connectors (MIC/LINE Channel)
Input Jacks (XLR type, 1/4" phone type), Foot Switch Jack (1/4" TRS phone type)
(GUITAR/INSTRUMENT Channel)
Input Jack (1/4" phone type), Foot Switch Jack (1/4" TRS phone type)
STEREO AUX IN Jack (Stereo miniature phone type), PHONES Jack (Stereo 1/4" phone type), AC Adaptor Jack
Power Supply DC 9 V: AC Adaptor or Dry Battery (LR6 (AA) type)(optional) x 6
Current Draw 235 mA
Size and Weight
Width 415 mm 16-3/8 inches
Depth 295 mm 11-5/8 inches
Height 250 mm 9-7/8 inches
Weight 5.2 kg 11 lbs. 8 oz.

* roland micro cube - 2w, 3.3kg - 18만
http://www.roland.com/products/en/Micro-CUBE/specs.html

* vox da5 - 5w, 3.5kg - 20만
http://www.voxamps.com/uk/da5/
    *  Number of Styles: 11
    * Number of Effects: 11 plus noise reduction
    * Signal Processing: 24-bit (both A/D and D/A conversion), 44.1 kHz sampling frequency
    * Input/Output Jacks: INPUT, AUX IN, MIC INPUT, LINE/PHONE
    * Power Amp Output: Maximum 5W RMS @ 8 ohms
    * Speaker: 1 x 6.5 inch, VOX original (8 ohm)
    * Power Supply: Six C batteries or the included AC adapter
    * Current Consumption: 390 mA
    * Dimensions: 10.51” x 7.05” x 10.51” (W x D x H)
    * Weight: 7.72 lbs.


* artec avenue - 20W, 6.2kg - 22만
http://www.artecsound.com/amps/avenue.htm
http://www.swingmusic.co.kr/shop/shopdetail.html?branduid=2114&search=&page=



//



//=====================================================================================

이펙터 전류량
OD-3 : 9mA
GE-7 : 10mA(Equalizer)
MT-2 : 20mA
CE-5 : 22 (Chorus Ensenble)
TU-3 : 30 (Tunner)
FZ-2 : 36mA

DD-3 : 45~65mA
DD-7 : 55mA(Delay),  Carbon: 1.5 hours, Alkaline: 6 hours.
RV-5 : 50 (Reverve)
PS-5 : 50mA (Super Shifter)

GT-10 : 800mA

* BBE Sonic Maximizer : 30mA, 예상 , DD-7의 반
 DC inlet: +9VDC min. 200mA
 Battery Life: 15 hours


* SADOWSKY PREAMP DI
 - 일반적인 PreAmp 의 전력 소비 0.5~2.5mA
 - 권장 어댑터 200mA


* PARA  DRIVER : 5mA
 - 권장 : 100mA


* DC 플러그 규격
A6 : 5.5 × 2.1 : 대부분 표준 이펙터용


* 안전사
http://www.anjunsa.com/

 - Linear Adaptor
AK-1209  - 9V - 300mA
AS-1209R - 9V - 600mA

 - SMPS
SM-0930K - 9V - 3000mA
SM-0945K - 9V - 4500mA
